Wotan B75T
MET7.791
By request
- Weight: 6300 kg
Contact us
| Documentation available | No | ||
|---|---|---|---|
| CE certificate present | No | ||
| Drive system | Conventional | ||
| Power [kW] | 7.0 | ||
| Number of axes [pcs.] | 3 | ||
| Spindle diameter [mm] | 75 | ||
| Table length [mm] | 1000 | ||
| Table width [mm | 800 | ||
| X-axis travel [mm] | 800 | ||
| Y-axis travel [mm] | 800 | ||
| Z-axis travel [mm] | 100 | ||
| Drilling capacity [mm] | 600 | ||
| Tool holder | ISO40 | ||
| Min. spindle speed [rpm] | 12.5 | ||
| Max. spindle speed [rpm] | 1000 | ||
| Options | Digital readout More info | ||
|
|||
| Transport dimensions | 4000mm x 2000mm x 2450mm (l x w x h) | ||
| Transport weight [kg] | 6300kg | ||
| Transport packages [pcs.] | 3 | ||
