| Documentation available | No |
|---|---|
| CE certificate present | No |
| Serial number | 80-0121-4445 |
| Drive system | Conventional |
| Power [kW] | 11.0 |
| Centre height [mm] | 260 |
| Swing over bed [mm] | 520 |
| Carriage turning diameter [mm] | 255 |
| Distance between centres [mm] | 1500 |
| Bed width [mm] | 400 |
| Spindle bore [mm] | 62 |
| Min. spindle speed [rpm] | 18 |
| Max. spindle speed [rpm] | 900 |
| Options | Quick-change tool post, Digital readout, Three-jaw chuck |
| Type of digital readout | Heidenhain |
| Transport dimensions | 3000mm x 1200mm x 1750mm (l x w x h) |
| Transport weight [kg] | 3000kg |
| Transport packages [pcs.] | 1 |
