Holz-her Sprint 1307
HOU.2177Sold
- Year: 2006
Contact us
| Year | 2006 |
|---|---|
| Documentation available | Yes |
Edgebander
Holz-Her Sprint 1317-2
Year of construction 2006
380V
Pre-milling unit (1961), 2x2.0kW, 12000 rpm
Multi Glue System (1905), For EVA and PUR glues in pattern and granule form.
Pressure unit (1913), Equipped with a pneumatic guillotine
Crosscut saw unit (1918), 2x 0.35 kW 9000rpm, Tiltable from 0 to 10 degrees
Radius scraper (1929), max R3Profile copy unit (1832), 1x0.22kW 9000rpm
Flat scraper (1964), top and bottom separately adjusted
Edge thickness 0.4 - 8 mm
Edge height 55 mm
Min cutting edge length 350 mm
Workpiece width min. 60mm
Workpiece length min. 180mm
Feed speed 8/16 m/min, stepless.
5950x1000x1700mm (LxWxH), +/- 2500kg
Documentation
If available for this device, you will find all available documentation below.
Photos
Download the photos here
